Drawing Dimensions / Wire Diameter: 116 X 89 Mm / 4 Mm

Highlight:

4mm double wire crate clips

wooden box joint-fit clips

drawing selection crate clips

Basic Infomation

Place of Origin: China

Brand Name: ORIENS

Payment & Shipping Terms

Gallery

4 mm Double Wire Wooden Box Clips - Drawing and Joint-Fit Selection

Product Description

4 mm Double Wire Wooden Box Clips - Drawing and Joint-Fit Selection

For engineering-led purchasing, the complete drawing is the starting point. This ORIENS double wire wooden box clip is identified by the supplied 116 x 89 mm profile dimensions and a 4 mm wire diameter. Use the drawing to discuss fit, rather than treating a photograph as a dimensional specification.

Read the Dimensions by Feature

Drawing information	How to use it
116 mm and 89 mm	Compare the dimensions at the reference locations shown on the drawing
4 mm wire diameter	Identify the round wire section; do not describe it as sheet thickness
Formed gripping ends	Compare their orientation with the engagement surfaces of the crate
Local dimensions and bends	Review the full profile, rather than substituting an assumed panel thickness

Keep Clip Dimensions and Wood Dimensions Separate

The wooden panel thickness, cleat width, cleat thickness and corner layout belong to the crate drawing. They are not automatically established by the clip's outline dimensions. Send both drawings together so the interfaces can be reviewed.

A Practical Drawing-Review Sequence

Identify the required clip drawing and revision.
Check that millimetre and inch annotations describe the same feature.
Compare the wire diameter and gripping-end geometry with the reference sample.
Show the intended installed position on the wooden joint.
Agree the sample review and acceptance points before committing to the production specification.

If your existing sketch uses different reference points, explain where each measurement starts and ends. Different numbers on two sketches do not by themselves prove that they represent different clip models.

Send a Complete Technical Inquiry

Include the drawing, joint details, required material and finish, quantity and destination. The minimum order quantity is 500 pieces. No tolerance, panel-thickness range or load rating should be inferred from this listing.

Email sales@oriensmetal.com. See the main 116 x 89 mm specification page and other crate clip designs.
